| Sr.No | Name of the Lab | Major Equipments | Area of Laboratory(Sqm) | Cost of Laboratory(Rs.) |
|---|---|---|---|---|
|
1 |
Machine lab. I & Machine lab. II |
1. AE make rectifier unit 3ph 360-440v, 50Hz ac input. Output 230-250v dc 0-100 A 2. Variable frequency drive with motor 0.5hp 3ph 415v 4pole&2pole |
145 |
1327565=00 |
|
2 |
Basic Electrical lab. |
|
73 |
147152=00 |
|
3 |
Measurement lab.
|
Phase Shift Transformer 3phase 1000VA,415V.
|
73 |
112264=00 |
|
4 |
Power electronics and IDC lab.
|
1. 1 ph dual converter fed separately excited Dc motor |
73 |
496479=00 |
|
5 |
Power system lab. |
1. Matlab software version-2007 at License no. 344845 matlab 10 users Simulink 10 users control system tool Box 10 users fuzzy logic tool box 2 Users neutral network tool box 2 users Signal processing tool box 10 users Simpower systems 10 users 2. Etap power station software 5 user Educational version make OTI VSA 3. DC network analyzer base kva 20mVA basekv20KV base impedance 2000 Ω |
73 |
1420329=00 |
|
6 |
Analog & Digital lab.
|
Analog lab trainer T2612.Ready to use circuit board
|
73 |
488833=00 |
|
7 |
Microprocessor and Microcontroller lab.
|
Logic analyzer model LA 2142 sampling 100 MHz 128k Channels
|
73 |
654482=00 |
|
8 |
Control system lab.+ NA + PLC
|
Study Of PID Control System
|
73 |
760258=00 |
|
9 |
Switchgear and protection lab. |
1. Simulation model of Merzprices Protection of transformers without % difference relay.Overall dimensions 100*400*700+600 mm 2. Simulation model of distance.Protection of transmission line without Impedance relay. Overall dimensions 100*400*700+600 mm 3. Universal solid state relay kit |
73 |
427832=00 |
|
10 |
High voltage lab. |
1. A.C High voltage transformer 60kva 2. 0-100 kv oil testing kit 3. HCL Intel Pentium 4 CPU @ 2.6 GHZ Intel mother board 256 MB 15”HCL Monitor 117 keys , Multimedia HCL Optical mouse with pad 52*CD ROM Drive on board 10/100 mbrs lan Controller 4. Computer CPU intel P-111 1GHz |
73 |
550218=00 |
|
11 |
Computer lab.I |
1. Computer CPU intel P-111 1GHz Motherboard Intel 815E. Chipest SD RAM 128MB F DD 1.44 mb ,Seagate Monitor, multimedia keyboard, Logitech mouse, dustcover mousepad 2. Computer CPU Intel PIII 1GHZ, Motherboard Intel 815 E CWP set SD RAM 128 MB , Monitor 15” Samtron, Multimedia keyboard, Logitech mouse, Dustcover, Speaker set 440W |
83 |
2728025=00 |
|
12 |
Testing Lab |
1. Auto range digital earth resistance tester 2. Microprocessor based cable fault localizer(0-10mag) |
— |
458861=00 |
|
|
|
|
Total |
9572309=00
|
